Pre-engineered office steel buildings

The price for the complete building

from .... /m2 without VAT

Related industries: Aircraft hangars, Goose farm

General:

Brand:

PK VESTA
Country/Origin of Goods:

Russia
Place of production:

Tula, Russia
FEA code:

9406903908
Supply of building kits:

Eurasia, Africa, Middle East, Latin America
Condition of buildings:

made "to order" from scratch (new)
Delivery :

land and/or sea (euro trucks and 40ft containers)
Structural warranty:

at least 50 years old
Product warranty:

1 to 5 years
Series:

INDI (Customized on order), TYP Series (Standard after project)
Scheme and form of payment:

40%x30%x30% and 70%x30% (L/C - letter of credit, T/T - bank transfer, D/P - payment after receiving a document confirming the shipment of goods by the seller)
Delivery conditions:

EXW, FOB, CIP, DAF, DDP

Load-bearing structures

Frame technologies:

LGF (cold-formed galvanized profiles), Rigid Framing (ferrous metal welded I beams) and HYBRID systems (LGF + Rigid Framing)
Element type:

H Beams (I-Beam), C Trusses/Columns (C-Channel)
Roof type:

Gable, single-slope, extensions, superstructures and flat roofs (single-span and multi-span)
Accessories:

All high-strength bolts (except anchor bolts), full trimming package, diagonal ties and connecting elements are included. Gates, doors, windows, skylights, canopies, transparent panels, solar panels
Steel type:

С245, С350, С345, C390 and C420
Galvanizing class:

only I (275 g/m2)
Metal Suppliers:

Russian Novolipetsk Iron and Steel Works and SeverStal
Secondary Elements:

Diagonal connections, secondary framing system (C-shaped, W- shaped. and Z- shaped)
Preparation level of elements:

High (numbering of elements taking into account cutting to the desired length, punching holes and a packing list for quickly finding the right pack at the construction site)
Connection of elements:

Only 100% bolted-together connection design (high strength and normal strength bolts)
Protection of ferrous metal elements:

Powder coating and/or hot dip galvanizing
Accounting for client technology:

Included if needed

Enclosing structures

Sheathing:

sandwich panels (mineral wool, polystyrene and PIR), sheet-by-element assembly (mineral wool), corrugated sheet (cold version), ventilated facades (metal cassettes, composite cassettes and porcelain stoneware – based on the mineral wool) and membrane roof
Accessories:

trimming package (flashing, framing openings, etc.), fasteners (self-tapping screws), skylights (or transparent panels), ventilation, sectional / swing gates, double-glazed windows (up to 6 chambers), solar panels and awnings.
Thermal circuit:

internal (panels from inside the frame are mounted) or external (all panels are mounted from the outside)
Basic colors (RAL):

White (9003), Gray (7004), Blue (5005), White-Aluminum (9006), Beige (1014), Yellow (1018), Green (6002), Light Gray (9002), Brown (8017)
Mineral wool density:

not less than 100 kg/cu.m.
Sheet thickness:

0.5mm, 0.6mm, 0.7mm, 0.8mm and 1mm (galvanized)
Preparation level of elements:

High (numbering of elements taking into account cutting to the desired length, punching holes and a packing list for quickly finding the right pack at the construction site)

Projects and Documents

Nordic Base Loads:

Snow (from 180 kg/sq.m. and above), Wind (from 32 kg/sq.m. and above) and Seismic – 6 points (MSK) Technological load: from 20 kg/sq.m. and higher.
Base loads for southern countries:

Snow (not taken into account), Wind (from 48 kg / sq.m. and above) and Seismic - 7 points and above (Richter Scale) Technological load: from 20 kg / sq.m. and higher.
Main projects:

assembly diagrams and instructions, diagrams of columns for the foundation, structure project (metal structures), cladding project (facade solutions), technical passport. Taking into account the state or commercial expertise.
Degree of fire resistance of the building:

IV-I
Certification:

ISO
Disclaimer:

when exporting buildings to other countries, different building codes are taken into account (European, American) and any other at the place of construction (Middle East, Africa, Asia, Latin America, etc.)

Making an I-shaped (H) welded beam

Metal cutting:

into strips of the desired length on a powerful high-precision laser machine
Assembly:

workpieces on the base
Welding:

all main elements
Process:

straightening elements on the mill
Partial welding:

bases of columns and stiffeners
Final preparation:

sand blasting / shot blasting / hot dip galvanizing
Painting:

included (upon request)
Factory primer:

included (20, 40, 60, 80, 100 microns and above)
Package:

in packs for euro trucks or 40 feet for containers

Making a C-profile

Process:

cold-formed metal profiling
Cutting and punching holes:

included (in auto mode)
Painting:

not included (high anti-corrosion properties)
Package:

in packs for euro trucks or 40 feet for containers

A modern office should be bright, spacious, inexpensive. Many companies cannot afford to build a capital office, so they rent it. PK VESTA offers a solution - inexpensive construction of office buildings from Rigid Framing and LSF. Modern construction technologies make it possible to build an office that meets modern requirements and standards within a few months.

Construction of office buildings

бвз офисные здания

To build an office from LSF, it is not necessary to equip a capital foundation, there is no need to collect a large package of permits for construction. After the work is completed, the premises are ready for use - all communications are connected, you can import furniture, equipment and open an office. If necessary, additional finishing of the building can be performed.

An office building can be ordered for a specific company or a complex of a number of office premises can be built, renting them out will bring additional profit. Given that the construction of the VMZ does not require large investments, the investments quickly pay off. Since prefabricated buildings are universal, they can be used for different purposes, you can order a building project, in which, in addition to the office itself, there is a warehouse, a garage for equipment, a beauty salon, a gym, etc.

Types of office buildings and structures

Before contemplating a prefabricated office, it is important to take into account current trends. It is necessary to provide maximum free access to visitors, while having rooms for confidential communication and mass meetings. It is economically feasible to have a multifunctional space. According to the BVZ technology, it is possible for enterprises to erect offices combined with a retail space or a warehouse. Depending on the load, light steel structures or a strong steel profile are used for the construction of buildings. Prefabricated structures differ in several ways:

sizes;
architectural design, it is possible to build structures with gable, shed and flat roofs;
planning, offices are placed along the longitudinal corridor system and the ring principle;
type of partitions: dismantled options are much more practical than stationary counterparts;
thermal conductivity of wall structures.

Sandwich panels differ in the thickness of the heat-insulating layer, protective materials. MDF, chipboard, plywood boards are used.

Design features of office buildings

особенности конструкции офиса из бвз

Prefabricated office buildings are a frame of light metal structures, sheathed with sandwich panels. They are light and strong, have high insulating characteristics. Steel structures are not only cheaper, but also faster to build compared to traditional buildings. The cost of building a sandwich panel office can be half that of a traditional office, and construction takes 5-8 weeks (depending on the size of the room).

Prefabricated office buildings can be erected at any time of the year. This is convenient, since the company can order the construction of an office in the off-season, when business activity is at a minimum. An important point is that an office from LSTK can be expanded or dismantled over time without any problems, transported to another place.

The assembly of a prefabricated building is a simple and fast process. But it is important that every step is carried out by professionals, since the durability and performance of the building is affected not only by the quality of the project, but also by the assembly of the structures itself.

Stages of building offices

The construction of pre-engineered buildings is much easier than capital structures. The process includes several steps:

Design - our company offers to choose one of the standard projects or develop an individual one, taking into account the requirements of the customer and the budget.
Production - PC VESTA is a manufacturing plant, uses high-quality materials, modern equipment and technologies. We guarantee the reliability and durability of the future object.
Delivery – we carry out delivery across Russia, to the countries of near and far abroad. Among our clients there are companies from different parts of the world.
Construction - for the BVZ, a capital foundation is not needed, it is quite light. This helps to save the customer a significant amount. The assembly of the frame is carried out directly at the construction site in accordance with the project. Then the floor is poured, the building is sheathed with sandwich panels, windows, doors, partitions are installed, the roof is being equipped.
Installation of communications - after erection, all communications provided for by the project are installed (heating, ventilation, plumbing, sewerage, electricity, etc.).
Delivery of the object - after the installation of the structure itself and engineering systems, the office is ready for operation.

PK VESTA carries out the construction of office buildings with delivery to anywhere in the world. We carry out a full range of works, from design to installation.

Benefits of an office building with sandwich panels

Using the technology of prefabricated buildings, it is possible to build office centers all year round. Within a period of up to 2 months, the customer receives an object ready for operation. A small office of prefabricated structures is rented out within a few weeks.
Design is carried out automatically. You can independently determine the amount of investment, choose the best option for the project.
For office buildings, modern environmentally friendly materials are used, which make it possible to build energy-efficient buildings that do not require large heating costs.
The frame structure provides spatial rigidity. Structures can be erected in earthquake-prone areas, on any type of soil.
The cost of prefabricated buildings is 30-40% less than capital construction.
Heavy machinery is not involved in the assembly of building structures. Office centers can be erected in microdistricts with dense buildings.
Buildings made of LMK or LSTK using sandwich panels look stylish, facades can be designed in any style, corporate symbols can be placed.
The panels have high soundproofing properties, they perfectly dampen street sounds, prefabricated buildings can be built near highways with heavy traffic.

Calculate the cost of building a turnkey office building

With the help of the WebSteel® electronic service, any user who does not have a technical education will be able to develop a project for the construction of an office building, the cost of construction depends on the type of rental used, the architectural complexity of the future object. The design autosystem is equipped with 3D visualization. You can think over the layout to the smallest detail. The calculator program on the Vesta website is available around the clock. You can pre-check the feasibility of investments without involving designers.

To find out the final cost of building an office building or get advice, fill out the form on the website or call our managers back.

Make an inquiry Price a building online

Choosing PK VESTA you will receive:

1.   The new philosophy and innovative business model of the “Smart Techno Design” allowing a client to quickly visualize pre-engineered steel buildings online in new service WebSteel, calculate main building costs instantly with automatic consideration of climatic zones (snow, wind and seismic), receive basic sketches with a detailed technical specification and order a turnkey building kit online from the factory to anywhere in the world.
2.   Unique building solutions from an old factory in the famous Russian industrial city of Tula (metal craftsmanship since the 17th century) offered specifically for you to design and manufacture energy-efficient custom prefabricated steel buildings made out of lightweight metal structures.
3.   Particular emphasis on the quality of our products, the high safety and reliability of our production facilities with the high automation of working processes and the latest IT technologies in the 24/7 format of customer service via the Internet in global markets (Eurasia, Africa, the Middle East and Latin America)

Technology comparison:

List	LSGF (profiles)	Rigid framing (welded beams)	Concrete

1) Metal consumption of Steel framing	Low	Medium	High
2) Load-bearing capacity	High	High	High
3) Complexity of manufacturing	Low	Medium	Medium

4) Complexity of erection	Low	Medium	Medium
5) Anticorrosion properties	High	Low	Low
6) Foundation costs	Low	Medium	High

7) Capacity in one vehicle	High	Medium	Low
8) Welding process	Missing	Available	Missing
9) Level of fire resistance	Medium	High	High

10) Manufacturing defect rate	The error in punching holes, cutting elements to the desired length - low.	The effect of mushroom and crescent after welding at the factory - medium / high.	Concrete chips, cracks, gaps and rebar displacement - low / medium.
11) Frequency of use in buildings with high humidity and ammonia aggressive environments	High	Low	Low

Comparison with competitors:

List	Factory PK VESTA	Competitors

1) Working experience in Russia and abroad	Since 1991 (without changing the name and phone numbers)	Since 2000 (many plants were founded later)
2) Owned (industrial and storage facilities with a jobsite and utilities)	Available	Missing (many plants rent facilities)
3) Metal consumption of steel framing	Low (28-31 kg/sq.m. – Northern countries)	Medium (32-35 kg/sq.m. – Northern countries)

4) Production of steel frames and sandwich panels (2in1)	Available	Missing (specialization in frames or only panels. Mass market)
5) Average work experience of a specialist	More than 10 years	Less than 5 years
6) Building Design anf engineering Experience	Since 1985 (part of specialists in engineering staff)	Since 2000 (the main building market)

Below are the prices for typical prefabricated buildings based on well-known construction technologies.

Services	Length, m / bay spacing, 6 m.
With 20% VAT. Delivery – EXW. Snow – 210 kg/sq.m., Wind – 23 kg/sq.m., Seismicity – up to 6 points.	30	36	42	48	54	60
Delivery terms for assembly and civil work, months (steel framing and cladding, assembly drawings, technical passport and certified engineering calculations)	1.5	1.5	1.5	1.5	1.5	1.5
Terms of Foundation and installation works, months.	2	2	2	2	2	2
Steel framing, RUB. (1 storey, No crane beam, Single span, Gable, with bolts, 100% bolted connections)	891588	1133396.4	1290252	1447108.8	1603964.4	1760820
Cladding system, RUB. (profiled sheet), shaped elements, fasteners	610708.8	711445.8	812183.4	912920.4	1013658.6	1114395.6
Foundation work, RUB. (pier, base beam included, insulated brickwork – 0.4m high)	450688.8	553452.6	630730.2	708008.4	785286.6	862564.2
Concrete floor, RUB. (thickness-150mm, loads - up to 2 tones / sq.m., with reinforced topping - a streamlined top layer of concrete)	555849.6	682591.2	777900.6	873210.6	968520	1063829.4
Assembly, RUB. (there are access roads, process technical water, electricity and a fence, cramped conditions are absent)	405619.8	498106.8	567657	637207.8	706758	776308.2
Number of Euro trucks, pieces	3	3	3	4	4	5
DELIVERY, RUB. (ground, up to 200 km)	24000	24000	24000	32000	32000	40000
Total from:	3457435.2	4244422.6	4833565.8	5430710.8	6019854.6	6616996.8
Width: 12 m 15 m 18 m 24 m 30 m 36 m 42 m Height: 4 m 6 m 8 m 10 m

Calculate by yourself

Is it possible to install crane equipment after the erection of the building?

Crane equipment can only be installed provided that the design loads were taken into account during the initial design of the pre-fabricated building.

Comparison of PK VESTA factory with other similar companies?

We do not doubt the quality of products and the work experience of the main players in the market of prefabricated buildings in Russia and abroad, but we draw attention to the fact that many of them adhere to the traditional business model of customer service, which is based on filling out the technical specs and calculating the building by company employees in office offline, receiving results and then sending the commercial proposal to the client by e-mail.

A distinctive feature of the PK Vesta plant is the unique on-line WebSteel system, which allows the client to design and instantly calculate the costs of a pre-fabricated building in real time via the Internet (snow, wind and seismic loads are digitized in Eurasia, the Middle East and Africa) The system is active 24 hours and 7 days a week. The client himself designs the building on-line, and our company makes it to order on the basis of the new philosophy of “Smart Techno Design» (free online design in the zone of technological restrictions of production) and a new approach to the production of «Smart Continuous Production» (a set of methods for manufacturing individual steel buildings with emphasis on quality, speed, automation and staff motivation) WebSteel is not a complex calculator or a large form for filling out the parameters of a technical building, but a powerful online platform created on the basis of algorithms, structural mechanics and research work.

Are the drawing sections for steel framing and cladding systems included into the building kit?

Yes. These sections are indeed included into the building kit. Usually a foreign client receives thee drawings and attach them to the local General Project to be confirmed by the local government authorities.

What are the terms for the design, manufacture, delivery and erectin of buildings from PK VESTA?

Due to the individual approach to international clients, the terms of design and manufacturing can vary significantly depending on the building structure, order volume, the availability of certain accessories in the form of internal columns, windows, doors, sky lights, crane beams, etc. In the WebSteel online system, the client will be able to easily calculate the certain design and production times for all buildings depending on the construction site in Eurasia, the Middle East or Africa. To do this, you need to spend not more than 10 minutes to enter the parameters of the building into the system.

Key dates

Designing sections of the project (frame, facades and foundation): approximately 2-3 weeks. The period depends on the level of customization of the pre-fabricated building
Manufacture: from 1 to 3 weeks for turnkey buildings with an area from 300 to 1000 m2. On average, it takes one week, largely depending on the size of the building and the structures used
Shipping: from 1 to 10 business days, an average of 4 business days.
Delivery: 2 to 3 business days (Eurasia). For export transactions (the Middle East and Africa), delivery may take up to 3-4 weeks.
Erection: 3 to 8 weeks. Typically, for buildings with an area of 500-600 m2, 2 weeks are required for the erection of light metal structures, 2-3 weeks for the installation of building envelopes with all additional materials (gates, doors, additional and decorative elements, etc.).
The commissioning of the object takes about 1 month (for buildings less than 1,000 m2) and depends on the level of the building (heating, electricity, lighting, etc.)

Important! Timing largely depends on the number of assembly teams, the number of people in the team, the level of qualifications, experience of installers and the availability of equipment. At your request, it is possible to reduce the duration of the entire process by 1.5-2 times.

Important! All terms are automatically calculated in the WebSteel online system, taking into account the load of the design office and production. The client can easily get this information in a commercial offer. Dates are fixed only upon payment at the stage of the transaction. Priority in terms is given to those customers who made the payment.

Is there a prefabricated building warranty?

Yes. PK VESTA provides up to 12 months of basic warranty for wall and roof sandwich panels, prefabricated steel buildings, as well as for doors and gates. Under an extended warranty, the period can be increased up to 5 years, which largely depends on the operating conditions of the building in a particular environment and country.

PK VESTA guarantees the composition and quality of the supplied products in full accordance with the statement of work and the technical documentation that accompanies the supplied products. In the event that during the warranty period the product is found to be defective or not in accordance with the terms of the contract, we will eliminate the defects at our own expense.

The warranty period normally starts from the date of signing of the acceptance certificate of products on the territory of the manufacturer. The terms for eliminating defects are agreed upon depending on the complexity of their elimination. The warranty repair period should not exceed 30 working days. The warranty period is extended for a period corresponding to the downtime caused by defects and repairs.

How are buildings made ouf of LSGF erected?

In such buildings, we pay special attention to modern building technology - cold-formed galvanized profiles (LSGF), which allows for some parameters of the building to reduce the metal consumption of the structure to about 30%, and therefore the final cost of the steel building.

These buildings are lightweight, have excellent anti-corrosion properties (they effectively resist a highly ammonia aggressive environment in the agricultural and storage industry), ease of installation and reduced transportation and foundation costs. Such buildings are widely used for car dealerships, shops, offices, warehouses, hangars, garages, production shops, agricultural farms, etc.

Below is the main chronology of the assembly of the building based on cold-formed galvanized profiles (car dealership Peugeot, Tula, Russia), designed in the WebSteel online system.

How are rigid framing buildings erected? (welded beams)

A building kit with the 100% bolted-together design is delivered to the construction site. Assembly drawings and all layouts are attached (translated into the required language beforehand) Vertical columns with bases are mounted first, then trusses with a secondary framing. Next wall and roof sandwich panels are mounted. And all trimming elements are sewn up with the further installation of gates, doors and windows.

The cost of the foundation largely depends on the type of soil, for the determination of which engineering and geological surveys are required. Based on the results of the geo study, the type of foundation and the depth of its foundation are selected. Then the exact cost of foundation work (the amount of concrete, materials and working time) is determined.

WebSteel online system calculates the cost of the foundation of a pre-fabricated building for conventional (most common) soils. However, in most cases, the calculation is quite accurate. At the negotiation stage, it can be used to draw up a preliminary construction budget.

After the conclusion of the transaction, the client receives the terms for the design and manufacture of a complete building (foundation plan) At the initial stage of design, the client receives a grid of columns, and at the stage of shipment of products from the territory of the plant - installation diagrams. The grid of columns helps the client to prepare the foundation in advance, in parallel with the manufacture of a set of pre-fabricated buildings in our production.

Below are the basic steps for installing the rigid framing building on the basis of a welded beam starting from the preparation of the foundation to the commissioning of the facility (Coca-Cola warehouse in Ryazan, Russia)

What are the advantages of prefabricated buildings from PK VESTA?

PK VESTA offers individual prefabricated steel buildings to international customers based on the unique WebSteel online system, which allows you to design and calculate the instant value of a custom building in real time via the Internet. When creating a web system, special attention was paid to minimizing the metal consumption of the steel building, which is the main feature of this online service. Another important advantage is an integrated approach - design, manufacture and erection of buildings anywhere in the world. PK VESTA provides a complete 100% factory turnkey building kit!

The technology of steel frame construction has long gained great popularity throughout the world, especially in Europe and North America. Lightweight metal structures are considered safe. Erection of these buildings is carried out within a few weeks due to the ease of construction, the absence of a massive capital foundation and the simple bolted-together connection of structural elements. The assembly of frames and girders at the construction site is carried out on bolted joints without the use of welding.

The steel frame is reliability, durability and fire resistance. It does not rot, does not sit down and does not dry out. The cost of insurance for this frame will be significantly lower than for wooden.

PK VESTA also pays special attention to buildings made out of LSGF, which can reach 30-36m in span and with an internal height of 8-10m. In general, this gives the client savings of up to 20-30% per frame compared to a classic ferrous metal frame (rigid framing made out of welded plates)

Do you provide assemby services for prefabricated buildings?

Yes. We provide erection services in the regions of Euroasia, the Middle East and Africa through a network of local certified erection teams. This approach minimizes the overall construction budget. The preliminary costs of civil work, erection and delivery are calculated in the WebSteel online system (based on the common soils)

Recommendations of PK VESTA:

In order to reduce costs, customers from remote regions are advised to use the services of third-party installation organizations. For customers who are interested in turnkey commissioning services, it is possible to conclude a single agreement with the regional representative of PK Vesta. You can also conclude separate contracts for the design, manufacture and installation, but this option will cost more.

What is the cost of 1 sq.m. of a prefabricated steel building?

The exact cost of 1 m2 of a prefabricated building can only be determined for typical modular buildings, as these are buildings with standard dimensions and finished projects. And then they are usually calculated with the most common loads (snow, wind and seismic) and are not always suitable for an individual request.

Since the WebSteel system allows you to calculate a custom building online according to certain parameters, the cost of 1 sq.m. for buildings can vary greatly. Minor changes in such parameters as the length, width, height of the building, its type of structure, number of floors, the presence of a crane beam, construction geography, types of enclosing structures, etc. may cause significant changes in the value of the building. In order not to mislead the client, we do not even give an approximate cost of 1 m2 at the negotiation stage, since the real price can differ significantly from the approximate one.

PK VESTA recommends that you spend no more than 10 minutes designing and instantly calculating your pre-fabricated building in WebSteel. If the project is complex and goes beyond the existing parameters, you need to create an individual quote, which is sent for calculation to the design office. You can find out the cost of the building roughly after 1 week. If there are tight deadlines, try to select or change the parameters for your building in the WebSteel system to get the instant online value for a building kit.

In any case, in the Websteel system, the client will receive the whole set of online documents for concluding a transaction (Commercial offer, Terms of Reference, free sketches and Contract). Usually the price proposal provides a detailed calculation by cost of each product category (steel framing, cladding systems, additional elements, erection, foundation and civil works, delivery, etc.)

Do you make custom or modular buildings?

Yes. We design and manufacture both custom and modular steel buildings shipped worldwide. Some modular buildings an even be manufactured in advanced in order to shorten the construction cycle for some international clients. These buildings usually consist of the certain modules combined together (see photos below) The erection process goes through pretty fast and can be carried out even by simple people.

The custom buildings are made on order taking into consideration the individual parameters of the building (dimensions, type of structure, type of cladding systems, color schemes and ext.)

What are the usual terms of payment, prepayment?

A typical payment scheme is 70% prepayment and 30% before shipment based on EXW (FOB or CIF are also available as terms of delivery) The following individual request can be considered: 80% deposit and 10-20% after the building is erected. Form of payment: L / C - letter of credit, T / T - bank transfer, D / P - payment after receiving a document confirming the shipment of goods by the seller)

Does the WebSteel system take into account the snow, wind and seismic loads on the building?

Yes. The WebSteel online system automatically takes into account both basic Russian and foreign loads while designing and instantly calculating the costs of pre-fabricated steel buildings at the construction site. WebSteel is not just a large form for filling in various parameters of buildings or a sophisticated calculator, but an advanced integrated online platform based on complex algorithms of building mechanics and research. Currently, many climatic zones (snow, wind and seismic) in Eurasia, the Middle East and Africa have already been digitized, allowing the client to make the most accurate calculations of individual buildings online.

When placing an order at the factory, all technical data and parameters for a prefabricated building are re-checked by our design office before issuing an order for design.

Why is installation supervision necessary and how much does this service cost?

The installation supervision service offered by PK VESTA includes the following activities:

external audit of installation works (assessment of the quality and effectiveness of installation at the facility).
individual consultations on installation work.
Installation Goals
Help the installation team resolve the difficulties that arise during the work.
Give an external assessment of the work of the installation team.
Installation supervision conditions
The service is provided in cases where the client himself hires an installation organization and wants to receive an external assessment of its work.
Installation supervision is carried out only after signing the contract.
The cost of a specialist’s visit from PK VESTA varies from $150 to $500 per day. The price depends on the duration of the work, the availability of housing, the level of responsibility, the job construction in a certain country and other similar factors.

Process: at the stage of concluding a transaction, PK Vesta includes the installation supervision service in the contract. At the same stage, the terms of cooperation are stipulated.

Important! PK VESTA is not directly responsible for the quality of installation; the company provides consulting and audit services to increase the efficiency of installation works

What is the difference between WebSteel and a complex calculator on a site or a simple form for filling in parameters?

WebSteel takes into account more than 500 000 major variations of prefabricated buildings, basic Russian and foreign building codes (SNIPs) and design loads, which is an important difference from a calculator or a large form to fill out. The preliminary most accurate cost of the pre-fabricated building and its accessories is calculated instantly on the remote online server, allowing the client to quickly and easily evaluate the preliminary construction budget and receive all the necessary technical documentation for free. Customer service via the Internet is based on the new philosophy of "Smart Techno Design" (online modeling of buildings in the area of technological production constraints)

It is important to understand that the calculation of the cost of the building and the design process takes place in real time on the server, and not in the office, as is the case with a complex form for filling in parameters. As for the calculator, this tool allows you to take into account only a small part of the factors affecting the value of the building. If additional elements appear or any changes take place, you have to do the calculation again using local calculation programs (software) In addition, the calculator and the form do not allow printing the necessary sketches with general and facade views in 3D and 2D formats.

Why does PK Vesta say that the WebSteel online system is the first in Eurasia? Are there no similar services in the country?

After conducting several of its own market research in the range of 2010-2018. in Russia and the CIS, we came to the conclusion that all construction companies work according to the traditional business model, which is based on filling out the technical specifications for the pre-fabricated building and the subsequent calculation of the project using local programs. There are online calculators (with a minimum number of parameters, without 3D visualization), configurators (with 3D visualization, but without calculating the cost online), simple calculation grids (for unified buildings without the ability to change basic parameters) or calculation systems (available only to specialized organizations).

WebSteel is the only free online system that allows you to design and calculate the cost of pre-fabricated buildings in real time via the Internet 24 hours a day, 7 days a week. PK VESTA provides the client with the opportunity to create an individual building image for free, while the user does not need to have a technical education. The process of online design takes place in a parametrized environment that takes into account production capabilities (taking into account technological production capabilities) Only for atypical and complex projects, the cost of a building must be calculated using local programs on an individual request.

We hope that you will appreciate the benefits of solving specific design problems with WebSteel when ordering buildings anywhere in the world

Advantages

Manufacturing accuracy

We have one of the lowest error margins in the manufacture of high-tech products in the international construction market in the range of + -1mm

Manufacturing accuracy

In the manufacture of load-bearing steel structures made out of LSGF - the error in punching holes, cutting profiles in length and the process of cold-formed profiling of elements is of great importance at the stage of assembly of the building. Unlike other plants, where the error in the center distance between the holes can reach + -3 or 4mm, we strictly adhere to a deviation of + -1mm on highly automated industrial European equipment, which gives an almost perfect guarantee for the successful installation of the steel frame (joining of different elements with many holes) when exporting a steel building to distant countries and regions (Asia, the Middle East or Africa) Plus, we exclude cases with the effect of mushroom, crescent and alignment of metal elements, which also often makes installation process more time consuming or even impossible. Work with thin metal borders on Art with us, where manufacturing accuracy helps put the building into operation faster for further successful work anywhere in the world.

Russian metal S350 with I class of galvanizing (275 g / sq.m.)

The use of any other classes of galvanizing II or III leads to a more rapid appearance of corrosion, especially if the building is used near water or with a high level of humidity or an ammonia aggressive environment indoors.

Russian metal S350 with I class of galvanizing (275 g / sq.m.)

The metallurgy in Russia, rich in resources, occupies one of the leading positions in the world in terms of output and quality. For the domestic market and export operations, PK VESTA uses only premium metal from well-known Russian metallurgical plants Severstal and Novolipetsk MK, which for many years have exported their products to many regions of the world - Eurasia, North and Latin America, the Middle East and Africa. The use of metal from other countries (for example, Chinese) may not always meet quality standards and impair the physical and mechanical properties of load-bearing structures.

Reliability factors

We do not "play with the reliability of the building" in order to reduce the metal consumption of the building to critical values and lower the cost of the steel frame. Some of our specialists have been designing steel buildings since 1980. taking into account modern building codes. Since that time, not a single building has fallen down!

Reliability factors

In addition to the quality of materials, the price of steel buildings largely depends on the design methods and the calculation of reliability factors. Among the players in the construction markets, there is a tendency to underestimate these coefficients (say, instead of 1 to 2 they make 1 to 1.5) in order to minimize the metal consumption of the steel structures and, accordingly, get a sharp decrease in the cost of the frame (up to 20-30%), which leads to the risk of building collapse and partial deformation of the main elements at the most unfavorable combination of loads (for example, a squalling long strong crosswind or a constant alternation of thaw and frost) And such cases cannot be ruled out. PK VESTA never goes down the red line, as it values its reputation and reliability of steel buildings. Since 1991, not a single building of PK VESTA has fallen down.

Production process

Welded beam of variable section for 36m span

Highly automated European equipment for cold-forming process of metal

Highly automated European equipment for rigid framing (welded beams)

Automated European equipment for sandwich panels

Column made out of black metal (welded plates)

Spot welding of stiffness ribs on column

Our works

all projects

187. Prefabricated dog training center 20W x 30L x 4H in Ramenskoye, Moscow Region, Russia

186. Pre-engineered cheese factory 18W x 30L x 4H in the Kanerga village, Russia.

185. Pre-engineered garment factory 24W x 27L x 3.5H in Bogorodsk, Russia

184. Prefabricated warehouse 24W x 60L x 6H for rent in Ryazan, Russia

183. Pre-engineered workshop 10W x 54L x 6.5H for the repair of carriage wheels in Ekibastuz, Kazakhstan

182. Prefabricated mini showroom 8W x 4D x 3H for the presentation of agricultural equipment in Tula, Russia

181. Prefabricated workshop/warehouse 18W x 36D x 8H with 5t crane in Aleksin, Russia

180. Prefabricated technical center 15W x 25L x 6H with an office in Arkhangelsk, Russia

179. Prefabricated auto repair shop 16W x 36D x 6H in Arkhangelsk, Russia

178. Pre-fabricated workshop 18W x 45L x 8H with a 5t crane beam for the production of technological equipment for the food industry in Ramenskoye, Russia

177. Pre-fabricated warehouse/workshop 24W x 42L x 6H for the storage of lumber in Ruza, MO, Russia

176. Pre-fabricated hangar 12W x 24L x 4H for storing boats in Omsk, Russia

Construction of office buildings

Types of office buildings and structures

Design features of office buildings

Stages of building offices

Benefits of an office building with sandwich panels

Calculate the cost of building a turnkey office building

Choosing PK VESTA you will receive:

Advantages

Production

Manufacturing accuracy

Products

Russian metal S350 with I class of galvanizing (275 g / sq.m.)

Engineering

Reliability factors

Production process

Our works
